Mooer System HF AP05
HF system
The Mooer AP05 is a wireless system designed for guitar, offering reliable, high-quality digital transmission on the 2.4 GHz frequency band. It includes a rechargeable transmitter and receiver, allowing for optimal freedom of movement with an effective range of 20 meters.
- ✓ 4 selectable channels (A/B/C/D)
- ✓ Uncompressed digital transmission
- ✓ 16bit/48kHz A/D conversion
- ✓ Latency less than 7 ms
- ✓ Up to 8 hours of battery life per charge
- ✓ USB-C cable included for charging
- ✓ Compact dimensions and lightweight (85g)
Technical data
| Frequency band | 2.4 GHz |
| Number of channels | 4 (A/B/C/D) |
| A/D Conversion | 16bit/48kHz |
| Transmission type | Uncompressed digital |
| Effective range | 20 meters |
| Frequency response | 20 Hz - 20 kHz |
| Latency | Less than 7 ms |
| Dynamic range | 95 dB |
| Autonomy | Until 8 a.m. |
| Charging time | 1.5 hours |
| Dimensions | 125 x 30 x 20 mm |
| Weight | 85 g |
| Accessories included | USB-C cable |
| Finishing | Gray |
Uses & Benefits
- Wireless freedom of movement with a reliable range of 20 meters
- Optimal audio quality thanks to uncompressed digital transmission
- Low latency for responsive, lag-free gameplay
- Simple to use with 4 channels to avoid interference
- Extended battery life of up to 8 hours for long sessions
- Fast charging via USB-C for quick availability
- Compact and lightweight design for easy transport and installation
